Description

Colour: Red

Rated current (A): 63

IP degree: IP67

No. of poles: 3P+N+E

Mechanical resistance: IK09

Reference: 6H

Type: Straight connector

Rated voltage: 346 – 415 V

Frequency: 50/60 Hz

Terminal tightening capacity: 6-16mm² flexible cables – 6-25mm² rigid cables

Cable clamp tightening capacity: 19.9-37 mm

Operating temperature: -25 +55 °C

Type of wiring: Mantle terminal

Type of material: Halogen-free in compliance with EN 60754-2

Electrocod: 2211

Glow wire test: 850 °C (active parts) – 650 °C (passive parts)

Total number of operations: > 2000

Breaking capacity at 1.1 Un: 79 A

Insulation resistance: > 10 M?
