Description

High quality and reliability with functional design and easy installation
Type A for both AC and DC application
Tested and Certified in accordance with IEC/BSEN61009-1
Breaking capacity: 6kA
Rated current: 20A
Number of poles: 1
RCD Type: AC – Ensures tripping for residual AC currents
Curve Type: C – trips between 5-10 times full load current. Suited for commercial applications where there is greater chance of higher short circuit currents, such as inductive loads or fluorescent lighting

Depth (mm)

18

mA

30

Width (mm) 72
Amp Rating 20

Poles 1

Ref E-DLY4120

Standards BSEN61009-1

RCD Type A

Short Circuit Breaking Capacity (kA) 6
