Description

ABC indicator A
Colour White
Security features optional security lock available
Total gross weight (g) includes packing 6550
Total net weight (g) excluding packaging 6187
Individual unit weight (g) 6187
Width mm 474
Height mm 260
Depth mm 130
Size/Dimensions (mm) 474X260X130
Surf area M^2 0.437
Technical
Associated standards BS EN 61439-3
Rated voltage 220-250V
Rated current 80A
Frequency 50-60Hz
Wiring system 2 pole
Ambient operating temperature -5 to 40°C (24hour average not exceeding 25°C)
Degree of protection IP4X
Width in number of modular spacings 22
Nature of supply AC
Rated fault current 30mA
DIN-rail yes
Extension possible yes
Type of cover steel
Type of door steel
Material housing steel
Plate thickness cabinet 1.2
Plate thickness door/cover 1.2
Mounting method surface
Number of outgoing ways 14

Additional information
